Uncompromising Precision in a Miniature Package: Introducing the Septentrio Mosaic G5

In the world of high-precision positioning, size and resilience are often at odds. The Septentrio Mosaic G5-P1 shatters this compromise, delivering professional-grade GNSS performance in an ultra-compact, rugged module. Designed for applications where space, power, and reliability are critical, the Mosaic G5 is engineered to be the trusted heart of your next-generation system.

Sophisticated Defense Against Interference: Built-in AIM+ Technology

Signal integrity is non-negotiable. The Mosaic G5 comes equipped with Septentrio's proprietary AIM+ (Advanced Interference Mitigation) technology. This sophisticated algorithm actively detects, identifies, and suppresses a wide range of RF interference, ensuring continuous and reliable positioning even in challenging electromagnetic environments. For autonomous vehicles, drones, and critical infrastructure, this built-in protection is a vital layer of security.

Extreme Miniaturization, Maximum Connectivity

With dimensions of just 22.8mm x 16.4mm x 2mm, the module sets a new standard for miniaturization without sacrificing interface options. It offers unparalleled connectivity flexibility including UART, USB, Ethernet, SDIO, GPIO, Event, and PPS. This allows for seamless integration into diverse architectures, from simple embedded systems to complex networked solutions, supporting data formats like RTCM 2.x/3.x for correction services.

Engineered for Diverse High-Stakes Applications

The Mosaic G5's robust feature set makes it the ideal choice for a spectrum of demanding fields. Its high sensitivity (down to -130 dBm) and low power operation (2.7V to 3.6V DC) are perfect for battery-powered devices. Key application domains include:

• Autonomous Driving & ADAS: Providing dependable, interference-proof positioning for navigation and safety systems.
• UAV/Drone Navigation: Enabling precise flight control, surveying, and delivery operations even near urban or noisy areas.
• Structural Health & Deformation Monitoring: Detecting minute movements in bridges, dams, and landslides with continuous, reliable data.
• Surveying & Mapping: Delivering the accuracy required for professional-grade GIS and land surveying equipment.
• Precision Timing: Utilizing the highly stable Pulse Per Second (PPS) output for secure network synchronization and time servers.

Part of the Trusted Mosaic G5 Series

As a member of Septentrio's Mosaic G5 series, this module benefits from a platform known for its high performance and reliability. Choosing the Mosaic G5-P1 means investing in a future-proof solution backed by Septentrio's expertise in cutting-edge GNSS technology.

Conclusion: The Definitive Compact GNSS Solution

The Septentrio Mosaic G5-P1 module redefines what is possible in a small-form-factor GNSS receiver. By combining military-grade anti-jamming capabilities, exceptional sensitivity, versatile interfaces, and an ultra-compact design, it solves the critical integration challenges faced by developers in robotics, autonomy, and precision measurement. For your mission-critical application, specify the module that leaves nothing to chance.
